Aipu Cat.5e UTP Network Indoor Cable Provide 100MHz Bandwidth in 100m, Typical Speed Rate: 100Mbps

Aipu Cat.5e UTP  Network  Indoor Cable Provide 100MHz Bandwidth in 100m, Typical Speed Rate: 100Mbps



1.Cat.5e UTP

Description

>Provide 100MHz bandwidth in 100m, typical speed rate: 100Mbps
>Widely used for horizontal cabling in working area and LAN
indoor
>Superior OFC (oxygen free copper) conductor, reliable electric
transmission, meets or exceeds Cat.5e standard, provide plentiful
redundancy for system link, fast and convenient installation

Standard

YD/T 1019-2013

Specification

Parameter Data
Conductor Diameter :24AWG
Insulation Diameter :0.88±0.01mm
Sheath Material: PVC
Overall Diameter: 5.4±0.2mm
Individual Conductor Resistance: ≤ 9.5Ω/100m
DC Resistance Unbalance :≤ 2.5%
Dielectric, DC, 1min :1Kv/1min
Capacity Max: 5.6nF/100m

Order Informaiton

Model No. Model Name Package Unit
APWT-5E-01 Cat.5e UTP 4Pairs 305m/Box Box






  • FOB Price: US $0.5 - 9,999 / Piece
  • Min.Order Quantity: 100 Piece/Pieces
  • Supply Ability: 10000 Piece/Pieces per Month
  • Aipu Cat.5e UTP Network Indoor Cable Provide 100MHz Bandwidth in 100m, Typical Speed Rate: 100Mbps : Aipu Cat.5e UTP Network Indoor Cable Provide 100MHz Bandwidth in 100m, Typical Speed Rate: 100Mbps
  • Product Detail

    Product Tags

    Aipu Cat.5e UTP  Network  Indoor Cable Provide 100MHz Bandwidth in 100m, Typical Speed Rate: 100Mbps



    1.Cat.5e UTP

    Description

    >Provide 100MHz bandwidth in 100m, typical speed rate: 100Mbps
    >Widely used for horizontal cabling in working area and LAN
    indoor
    >Superior OFC (oxygen free copper) conductor, reliable electric
    transmission, meets or exceeds Cat.5e standard, provide plentiful
    redundancy for system link, fast and convenient installation

    Standard

    YD/T 1019-2013

    Specification

    Parameter Data
    Conductor Diameter :24AWG
    Insulation Diameter :0.88±0.01mm
    Sheath Material: PVC
    Overall Diameter: 5.4±0.2mm
    Individual Conductor Resistance: ≤ 9.5Ω/100m
    DC Resistance Unbalance :≤ 2.5%
    Dielectric, DC, 1min :1Kv/1min
    Capacity Max: 5.6nF/100m

    Order Informaiton

    Model No. Model Name Package Unit
    APWT-5E-01 Cat.5e UTP 4Pairs 305m/Box Box
