Aipu 218Y/B to BS6500 Light Coble Household Cable H03VVH2-F 2×0.5/H03VVH2-F 2×0.75 3 Cores Appliances Cable

Application
For use on small appliances with low mechanical stress and for connection for
light household appliances.
Constructions
1. Conductor: Class 5 Oxygen Free Copper
2. Insulation: PVC, LSZH
3. Identification:
            2 Cores: Blue & Brown
           3 Core: Green/Yellow, Blue & Brown
           4 Core: Green/Yellow, Brown, Black & Grey
           5 Core: Green/Yellow, Blue & Brown & Black
4. Sheath: PVC, LSZH

  • FOB Price: US $0.5 - 9,999 / Piece
  • Min.Order Quantity: 100 Piece/Pieces
  • Supply Ability: 10000 Piece/Pieces per Month
  • Product Detail

    Product Tags

    Aipu 218Y/B to BS6500 Light Household Cable

    Application
    For use on small appliances with low mechanical stress and for connection for
    light household appliances.
    Constructions
    1. Conductor: Class 5 Oxygen Free Copper
    2. Insulation: PVC, LSZH
    3. Identification:
                2 Cores: Blue & Brown
               3 Core: Green/Yellow, Blue & Brown
               4 Core: Green/Yellow, Brown, Black & Grey
               5 Core: Green/Yellow, Blue & Brown & Black
    4. Sheath: PVC, LSZH

    »Installation Temperature: Above 0°C
    » Operating Temperature: -15°C ~ 70°C
    » Rated Voltage: 300/300V
    » Test Voltage: 2000V
    Reference Standards
    » BS6500
    » BS EN 50525-2-11
    » BS EN 60228
    » BS EN 50363
    » RoHS Directives
    » IEC60332-1

    微信图片_202306121657571 微信图片_202306121657572 微信图片_202306121657573 微信图片_202306121657574 微信图片_202306121657575 微信图片_202306121657576
