Aipu 309Y to BS6500 Green/Yellow, Brown, Black Grey & Blue 4 Cores Industrial Cable Light Wire

Application
For use on small appliances with low mechanical stress and for connection for
light household appliances to 90°C.
Constructions
1. Conductor: Class 5 Oxygen Free Copper
2. Insulation: PVC
3. Identification:
                        2 Cores: Blue & Brown
                        3 Core: Green/Yellow, Blue & Brown
                        4 Core: Green/Yellow, Brown, Black & Grey
                        5 Core: Green/Yellow, Brown, Black Grey & Blue
4. Sheath: PVC

Product Detail

Product Tags

Aipu 309Y to BS6500 Green/Yellow, Brown, Black Grey & Blue 4 Cores Industrial Cable

Application
For use on small appliances with low mechanical stress and for connection for
light household appliances to 90°C.
Constructions
1. Conductor: Class 5 Oxygen Free Copper
2. Insulation: PVC
3. Identification:
                        2 Cores: Blue & Brown
                        3 Core: Green/Yellow, Blue & Brown
                        4 Core: Green/Yellow, Brown, Black & Grey
                        5 Core: Green/Yellow, Brown, Black Grey & Blue
4. Sheath: PVC
» Installation Temperature: Above 0°C
» Operating Temperature: -15°C ~ 90°C
» Rated Voltage: 300/500V
» Test Voltage: 2000V
Reference Standards
» BS6500
