Aipu EIA RS-485 Cable LSZH Data Communication Automation System Twist Pairs Cable

Constructions
1. Conductor: Stranded Tinned Copper Wire
2. Insulation: S-PE, S-FPE
3. Cabling: Twist Pairs laying-up
4. Screened: Individually Screened (Optional)
Al-PET tape with Tinned Copper Drain Wire
Tinned Copper Wire Braided Screen
Al-PET Tape & Tinned Copper Braided
5. Bedding for Armoured Cable (Where Applicable):
Polyethylene (PE)
PVC
6. Armour (Where Applicable): Galvanized Steel Wire
7. Oversheath: PVC/LSZH

Application
For data communication and automation systems, microprocessor to device, etc


Product Detail

Product Tags

Application
For data communication and automation systems, microprocessor to device, etc.
»» Installation Temperature: Above 0°C
»»Operating Temperature: -15°C ~ 65°C
Constructions

1. Conductor: Stranded Tinned Copper Wire
2. Insulation: S-PE, S-FPE
3. Cabling: Twist Pairs laying-up
4. Screened: Individually Screened (Optional)
                      Al-PET tape with Tinned Copper Drain Wire
                      Tinned Copper Wire Braided Screen
                     Al-PET Tape & Tinned Copper Braided

5. Bedding for Armoured Cable (Where Applicable):  Polyethylene (PE)
                                                                                    PVC
6. Armour (Where Applicable): Galvanized Steel Wire
7. Oversheath: PVC/LSZH

Reference Standards
»» TIA/EIA-485
»» BS EN 50288-7
»» BS EN 60228
»» BS EN 50290
»» RoHS Directives

Identification of Insulation

1P : White, Blue            3P :White, Green
2P  :White, Yellow         4P: White, Brown

Electrical Performance

Working Voltage: 300V
Characteristic Impedance :120 Ω ± 15 Ω
Velocity of Propagation S-FPE: 78%, SPE: 66%
Conductor DCR
57.0 Ω/km (Max. @ 20°C) for 22AWG
91.80 Ω/km (Max. @ 20°C) for 24AWG
