Aipu RS-232 Cable Application Multi-Core Foil & Braid Screened Transmission as Audio Control and Instrumentation Cables

Application

For low data rate transmission as audio, control and instrumentation cables.

Constructions

1.Conductor: Stranded Tinned Copper Wire
2. Insulation: PVC
3. Cabling: Cores, Twist Pairs laying-up
4. Screened: Al-PET Tape & Tinned Copper Braided
5. Sheath: PVC/LSZH

»» Installation Temperature: Above 0°C
»»Operating Temperature: -15°C ~ 65°C

Reference Standards

»» UL2464
»» BS EN 60228
»» BS EN 50290
»» RoHS Directives

Identification of Insulation

Electrical Performance

Working Voltage 150V
Test Voltage 800V
Conductor DCR 91.80 Ω/km (Max. @ 20°C)

Contact us to get product catalog
