Aipu RS-232 Cable Multi Pairs Foil Screened Audio Control Instrumentation Cables

Application
For low data rate transmission as audio, control and instrumentation cables.
Constructions
1. Conductor: Stranded Tinned Copper Wire
2. Insulation: PE, PVC, Polyolefin
3. Cabling: Cores, Twist Pairs laying-up
4. Screened: Al-PET tape with Tinned Copper Drain Wire
5. Sheath: PVC/LSZH

»» Installation Temperature: Above 0°C
»»Operating Temperature: -15°C ~ 65°C


Product Detail

Product Tags

Application
For low data rate transmission as audio, control and instrumentation cables.
Constructions
1. Conductor: Stranded Tinned Copper Wire
2. Insulation: PE, PVC, Polyolefin
3. Cabling: Cores, Twist Pairs laying-up
4. Screened: Al-PET tape with Tinned Copper Drain Wire
5. Sheath: PVC/LSZH

»» Installation Temperature: Above 0°C
»»Operating Temperature: -15°C ~ 65°C

Reference Standards
»» BS EN 50288-7
»» BS EN 60228
»» BS EN 50290
»» RoHS Directives

Identification of Insulation

Electrical Performance

Working Voltage : 300V
Test Voltage : 800V
Conductor DCR :91.80 Ω/km (Max. @ 20°C)
