Aipu RS-232 CAD/CAM Cable Multi-Pair Foil & Braid Screened Computer Cables PVC/LSZH

Application

For EIA RS-232 and CAD/CAM applications, used as computer cables.

Constructions
1. Conductor: Stranded Tinned Copper Wire
2. Insulation: PVC, Polyolefin
3. Cabling: Cores, Twist Pairs laying-up
4. Screened: Al-PET Tape & Tinned Copper Braided
5. Sheath: PVC/LSZH

»» Installation Temperature: Above 0°C
»»Operating Temperature: -15°C ~ 65°C

Reference Standards
»» UL 2464
»» BS EN 60228
»» BS EN 50290
»» RoHS Directives

Identification of Insulation

Electrical Performance

Working Voltage :300V
Test Voltage :800V
Conductor DCR:57.0 Ω/km (Max. @ 20°C) for 22AWG
                         :91.80 Ω/km (Max. @ 20°C) for 24AWG
